Product Overview
Provides durability and protection required for electrical enclosures and control panels. The electrostatic powder coating process creates hard, uniform finish that withstands demands of industrial environments.
Polyester Electrostatic Powder Coating Color Board is a high-quality, environmentally friendly building material produced by applying a dry polyester powder to a pre-treated metal substrate (such as aluminum or galvanized steel) through an electrostatic process, which is then cured under heat to form a durable, smooth coating. This thermosetting finish offers excellent mechanical properties, a wide range of color options, and superior resistance to chipping and abrasion compared to liquid paints. It is an ideal choice for architectural interiors, furniture, and applications requiring a robust and aesthetically pleasing finish at a competitive cost.
Product Description
Eectrostatic powder spray coating boards utilize internationally advanced technology to achieve one-time coatng formation The fuly automated production line ersuresgreen and dean production.Both the equipment and coating materials hold multiple national irvention patents,completely revolutionizing the traditional production methods of color-coated boards.Ths innowation addresses the drawbacks of heavy paint pollution,unsafe operations,and high energy consumption in the original process.The per- formance of the powder coating supasses tha of traditional paint coatings in many aspects.
The raw materials used in the powder coating are based on vari- ous high-perfomance newmaterialscontaining no sohents and zero VOC.They are energy-efficient,safeerwironmentaly friendly, andexhibit ecellentadhesion,weather resistance,and corrosion re- sistance Eectrostatic powder-coated cois have completely trans formed the traditional production methods of color-cOated cols Our company employs high-molecular powder coatings,utilizing
the principle of electrostatic attraction to ensure the powder is evenly and fimly adsorbed onto the surface of the substrate.After high-temperature curing.the coating is formed,overcoming the issuesof heavy paint plution,unsafe operations and high energy.
Different substrates such as galvanized,aluminum zinc coated,galvanized aluminum magnesium coated,cold plate,stainless steel,aluminum plate,etc.can be selected based on factors such as the purpose,structural forming.and usage environment ofthe powder coated plate.Materials such asDX51D,DX52D,DX53D,S350GD,S550GD,etc.can also be selected as needed
Specifiction
Key Features & Highlights
Superior scratch and impact resistance
Uniform coating thickness
Excellent edge coverage
Eco-friendly, VOC-free process
Custom color options
Application field
Electrical cabinets and enclosures
Distribution boxes and panels
Control cabinet manufacturing
Industrial electrical equipment
Power distribution systems
Why Choose Us
Advanced Production Lines: High-speed continuous hot-dip galvanizing equipment.
Strict Quality Control: 100% surface inspection and mechanical property testing.
Global Certification: ISO, ASTM, EN compliance for international markets.
Customization: Zinc coating, thickness, width, and surface treatments tailored to customer needs.
Export Expertise: Long-term supply to over 80 countries with professional logistics support.
FAQ
Q1: Why choose powder coating for electrical cabinets?
A: Powder coating provides superior durability, scratch resistance, and edge coverage compared to liquid paint. The thick, uniform coating protects cabinets in industrial environments. VOC-free process is environmentally friendly.
Q2: What colors are standard for electrical cabinets?
A: RAL 7035 (light gray) is most common for electrical enclosures. RAL 7032 (pebble gray) also popular. Custom colors available for specific requirements or brand identity.
Q3: Does powder coating affect electrical conductivity?
A: Powder coating is electrically insulating. Grounding requirements must be addressed through design - use grounding studs, washers, or conductive gaskets at assembly joints. Follow electrical codes for enclosure grounding.
Q4: Can powder coated cabinets be used outdoors?
A: Polyester powder coating provides good outdoor durability (10-15 years). For extended outdoor life or harsh environments, consider polyurethane or hybrid powder formulations with enhanced UV resistance.
Q5: What is the typical coating thickness?
A: Standard powder coating thickness is 60-80 microns. Thicker coatings (100-120 microns) available for enhanced protection. Thickness is controlled and consistent across entire surface, including edges.
DX51D Galvanized steel is a type of steel that has been treated with zinc to enhance its corrosion resistance.
1.Surface structure code / Not just polished
Normal zinc flower N NS Small zinc flower M MS Zinc free flower F FS Zinc ferroalloy ZF ZFS
2.Surface quality code
Ordinary surface FA Advanced surface FC Higher surface FB
3.Surface treatment symbol
Passivation C Unction O Paint sealant L Phosphating P Don't deal with U
Service
Custom Orders: Tailored sizes, thicknesses, and coatings to meet customer needs.
Quality Assurance: Rigorous testing for surface quality and coating thickness to ensure high standards.
Flexible Payment Options: Multiple payment methods like T/T, LC, and PayPal.
Global Delivery: Timely and reliable worldwide delivery for large and small orders.
Packaging: Safe packaging suitable for international shipment.
