Engineered for high-speed automated production, this continuous coil format minimizes material handling while maximizing throughput. The smooth, non-spangle surface ensures consistent quality throughout the coil length, with excellent unwinding characteristics that prevent line stoppages. Ideal for roll forming, continuous stamping, and tube manufacturing operations.
Product Overview
Engineered for high-speed automated production, this continuous coil format minimizes material handling while maximizing throughput. The smooth, non-spangle surface ensures consistent quality throughout the coil length, with excellent unwinding characteristics that prevent line stoppages. Ideal for roll forming, continuous stamping, and tube manufacturing operations.
The company has ecellent equipment configuration and strong technical force.It can produce galvanized steel sheets of various speciications ranging from 0.10 to 1.20×700~1250 ×C.The ultra-thin Large zine gavanized shets produced by 0.10~0.15×1000C are at the international ad- vanced level.Thedomestic gap has an incomparable advantage.
Product Description
Produced by Shandong Jinlisheng New Materials, Plain Galvanized Steel Coil uses high-quality cold-rolled steel coils as raw materials, processed via hot-dip galvanizing (aluminum-zinc-silicon coating optional) and chromating. It has a zinc coating weight of 30-120g/m², with three surface options: regular, minimal, and zero spangle. Specifications include thickness 0.09-1.2mm, width 500-1250mm, max coil weight 10MT, and inner diameter 508/610mm. It offers good corrosion resistance, fitting humid/coastal areas, and excellent processability for slitting, welding, and bending. Widely used as a base for color-coated steel, and in construction (roofs, ducts), home appliances (refrigerator backplanes), and container manufacturing.
Specifiction
Continuous coil format optimizes automated processing efficiency
Consistent surface quality from coil start to end
Excellent unwinding performance prevents production interruptions
Multiple coil weights and ID options for line compatibility
Tight strip shape control for stable processing
Application field
Roll forming lines for roofing and wall cladding
Continuous stamping and pressing operations
Tube and pipe manufacturing
Automotive component production lines
High-volume appliance manufacturing
Why Choose Us
Advanced Production Lines: High-speed continuous hot-dip galvanizing equipment.
Strict Quality Control: 100% surface inspection and mechanical property testing.
Global Certification: ISO, ASTM, EN compliance for international markets.
Customization: Zinc coating, thickness, width, and surface treatments tailored to customer needs.
Export Expertise: Long-term supply to over 80 countries with professional logistics support.
FAQ
Q1: What is the maximum coil weight you can supply?
A: Maximum coil weight is 12 MT for standard specifications. Larger coils up to 15 MT available for special orders with adequate equipment. Heavier coils reduce changeover frequency and improve production efficiency.
Q2: Can you supply oscillate wound coils?
A: Yes, oscillate (traverse) winding is available for narrow slit coils. This increases coil weight 3-5x compared to ribbon winding, reducing changeovers and improving efficiency for narrow strip applications.
Q3: What is the recommended storage time for galvanized coils?
A: Use within 6 months for optimal performance. Store indoors in dry, ventilated conditions. Avoid temperature fluctuations that cause condensation. White rust may form after 3-6 months but typically doesn't affect performance if removed.
Q4: Do you provide coil set removal service?
A: Yes, our tension leveling process removes coil set and corrects edge wave. This improves flatness for subsequent processing and eliminates springback issues in roll forming operations.
Q5: What is the minimum order quantity for coils?
A: Standard MOQ is 25 tons per size. Mixed loads of different specifications possible for total 25+ tons. Smaller quantities available at premium pricing. Long-term contracts offer better pricing and scheduling flexibility.
DX51D Galvanized steel is a type of steel that has been treated with zinc to enhance its corrosion resistance.
1.Surface structure code / Not just polished
Normal zinc flower N NS Small zinc flower M MS Zinc free flower F FS Zinc ferroalloy ZF ZFS
2.Surface quality code
Ordinary surface FA Advanced surface FC Higher surface FB
3.Surface treatment symbol
Passivation C Unction O Paint sealant L Phosphating P Don't deal with U
Service
Custom Orders: Tailored sizes, thicknesses, and coatings to meet customer needs.
Quality Assurance: Rigorous testing for surface quality and coating thickness to ensure high standards.
Flexible Payment Options: Multiple payment methods like T/T, LC, and PayPal.
Global Delivery: Timely and reliable worldwide delivery for large and small orders.
Packaging: Safe packaging suitable for international shipment.
